Prekės kodas: 1364140
Turimas kiekis: 5
| Garantija: | 36 |
| Gamintojas: | DAHUA |
| Techninė informacija | |
| Alarm In | 1 |
| Alarm Out | 1 |
| Audio-In | 1 |
| Audio-Out | 1 |
| Camera design | Other |
| Category Code | FNC |
| Dimensions | 44.6 mm × Φ126.2 mm |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Environment | Outdoor |
| Lens Mount | M12 |
| MicroSD Card Slot | 1 |
| Microphone | Built-in |
| Min. Illumination | 0.006 |
| Operating temperature range | –10°C to +50°C |
| Pixel Resolution | 5 |
| Power consumption | 7.3 |
| Power options | 12V/PoE |
| Power supply requirements | 12V DC/PoE |
| Sensor size | 1/2.7" |
| Supports card capacities up to | 256GB |
| Unit Box Height | 0.14 |
| Unit Box Length | 0.16 |
| Unit Box Width | 0.16 |
| Vendor Homepage | www.dahuasecurity.com/products/All-Products/Network-Cameras/WizMind-Series/Panoramic-Series/Fisheye/IPC-EW5541-AS |
1/2.7” 5MP progressive scan CMOS,
2592×1944 @ 25FPS
Minimum illumination: 0.006 Lux@F2.0 (Color, 30IRE). 0.0006 Lux@F2.0 (B/W, 30IRE), 0 Lux (Illuminator on)
Illumination Distance: 10 m
True Day/Night ICR, BLC/HLC/True WDR 120 dB/3D DNR
1.4 mm fixed lens (180°)
Memory Slot: Micro SD, Max 256GB,
1/1 Alarm In/Out, 1/1 Audio In/Out (+Built in Mic)
H.265; H.264; H.264H; H.264B; MJPEG encoding, ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P
No protection, indoor use only, -10°C~+50°C, PoE / 12VDC power, 7.3W, metal + plastic case
IVS (Perimeter Protection): Tripwire; intrusion
Support people counting in area, and displaying and outputting yearly/monthly/daily reports (matching devices are needed); support people counting in 4 areas
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.
Free IP monitoring software available
Advanced Intelligent Functions: Tripwire, Intrusion, Heat map, People counting
